Manufacturer Part No.: 004331012 80A

ETI DIN 80mm Bolted Contact Ultra Quick Semiconductor Protection Fuses: 80 Amps, 690 Vac/50 kA, 440 Vdc/25kA, Operating Class: aR, Size: NH00C-T/80mm

Manufacturer: ETI
Country of Origin : Slovenia
Technical Datasheet:
Packaging Quantity: 3
Minimum Order Quantity: 3
Order in Multiples of Quantity: 3
Required Quantity:
Price on Request

Product Salient Features:

  • Class aR Ultra Quick Semiconductor Protection Fuses
  • Confirming to DIN 43653, IEC 60269-4-1, CE
  • All Fuses have blown fuse indicator


  • Available Rated Current: 6, 10, 16, 20, 25, 35, 40, 50, 63, 80, 100, 125 Amps
  • Wide range of Fuse-Bases and Accessories available at extra cost
Technical Data
Manufacturer: ETI
Series: 0043310**
Fuse Type: Ultra Quick 80mm Bolted Contact
Operating Class: aR
Current Rating (A): 80 Amps
Voltage Rating (Vac): 690 Vac
AC Breaking Capacity (kA): 50 kA
Voltage Rating (Vdc): 440 Vdc
DC Breaking Capacity (kA): 25 kA
Size: NH000/NH00C-T-80mm
Pre-Arcing I2t Value A2s: 1100
Total I2t Value A2s: 5350
Power Loss (W): 25.0 W
Fuse Blown Indicator: Visual Indicator
Standards: CE/IEC60269-4/DIN43653
Packaging Quantity (Pcs.): 3
Weight (Grams): 180
